Layer 2 Switch sa (5) GbE RJ45 portova, uključujući (1) 802.3af PoE ulaz.
USV Flex Mini može da se napaja ili sa PoE (preko porta 1) ili sa uključenim USB-C adapterom za napajanje*. Ovaj prekidač se takođe može nadgledati ili konfigurisati sa bilo kog mesta pomoću moćne, intuitivne veb aplikacije UniFi Netvork i mobilne aplikacije.
Specifikacije:
Mechanical |
Dimensions |
107.16 x 70.15 x 21.17 mm (4.22 x 2.76 x 0.83") |
Weight |
150 g (5.29 oz) |
Interfaces Networking PoE In Management |
(5) 10/100/1000 Mbps RJ45 Ports 802.3af/at PoE (Pins 1, 2+; 3, 6-) Ethernet In-Band |
Total Non-Blocking Throughput |
5 Gbps |
Switching Capacity |
10 Gbps |
Forwarding Rate |
7.44 Mpps |
Power Method |
USB Type C, 5V 802.3af/at PoE (44 - 57VDC, 0.05 - 0.04A) |
Power Supply |
5V, 1A Power Adapter* |
Voltage Range USB Type C 802.3af/at PoE |
4.7 - 5.3VDC 44 - 57VDC |
Max. Power Consumption |
2.5W |
LEDs System RJ45 Data Ports |
Status Speed/Link/Activity |
ESD/EMP Protection |
± 16kV Air, ± 12kV Contact |
Shock and Vibration |
ETSI300-019-1.4 Standard |
Operating Temperature |
-5 to 45° C (23 to 113° F) |
Operating Humidity |
10 to 90% Noncondensing |
Certifications |
CE, FCC, IC |
