Ports
|
(1) uplink Gigabit Ethernet port, with POE-in support (802.3af) |
|---|
|
Mounting
|
The access point ships with a (black) mount clip to attach to suspended ceiling rails, and a (white) mount clip to attach to solid surfaces (wall/ceiling). |
|---|
|
Connectivity, standard
|
IEEE 802.11ac, 802.11n |
|---|
|
Input voltage
|
Power over Ethernet (POE): 802.3af (class 3) or DC power (12V). Power sources sold separately. |
|---|
|
Certifications
|
UL 2043 plenum rating EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments) Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE) |
|---|
|
Wi-Fi antenna
|
Integrated down-tilt omni-directional antennas with maximum individual antenna gain of 3.3dBi in 2.4GHz and 5.8dBi in 5GHz |
|---|
| Radio coverage |
Dual radio for simultaneous dual-band operation. 5 GHz 802.11ac 2x2 MIMO for up to 867 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5). 2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4). |
|---|
|
Minimum dimensions
( H x W x D)
|
34 x 152 x 152 mm |
|---|
|
Weight
|
193 g |
|---|
